DK20 Heat Press for Kydex and T-Shirts

DK20 Heat Press for Kydex and T-Shirts

Regular price $1,450.00
Regular price $1,325.00 Sale price $1,450.00
Sale Sold out
Shipping calculated at checkout.

Top of the line heat press for our Kydex holster and sheath makers!  The DK20 Digital Knight largest clamshell is 16" x 20" and opens for full access to the lower bottom table.

It is important to note that the back of the heat platen raises above and away from the bottom table.  This provides better access than other clamshell presses.

The frame support allows you to slide shirts over the table with complete drape space around and underneath the loading area. Interchangeable bottom tables for smaller pressing areas are available.

Our home based businesses with space limitations will love the size, portability, and mobility compared to the over-weight swing away presses.  Pull it off the shelf, use it, and put it back on the shelf so you can use the counter space for something else.

The DK20 can be easily upgraded to an automatic release press with the "Pop-Up" upgrade. This allows for faster semi-automatic garment production at a very reasonable price.  Add to this the twin station upgrade as well, and you have the ultimate clamshell dual station light production machine.

By simply allowing the press to complete its timed cycle it will automatically release upon completion.

Add the automatic release feature to your machine by selecting (Include) the drop down option above.


  • All-Thread™ table loading design
  • Fully digital temperature control 32°-600°F range
  • Automatic digital timer & dual pre-press timer
  • Digital Pressure Bar Graph
  • Super-portable light machine weight - 103 lbs!
  • Extreme high pressure capability
  • Hardened high-strength pivot points
  • Interchangeable tables
  • Solid Steel framework
  • SuperCoil-Microwinding™ heater technology
  • Self lifting gas-spring, & wide opening
  • Temperature readout accuracy +-2°F - can show °C or °F
  • User selectable end-of-cycle alarms
  • Records number of pressing cycles done
  • Teflon-coated 3/4" thick heat platen


  • FREE LIFETIME Tech Support!
  • Lifetime warranty on heat platen
  • 5-year warranty on frame
  • 3-year warranty on controller
  • 1 year warranty on parts


  • Weight: 103 Lbs
  • Electrical: 1800W / 15A / 110V
  • Shipping Dims: 36"L x 17"W x 16"H
